32” (794mm) stainless steel legs (for single unit)
12” (273mm) stainless steel legs (for double unit)
Burner door opens easily for ignition, cleaning or adjustment, without removal of any fastenings
Vitreous fiber insulation at top, back, sides, bottom and doors
47-1/4” x 36” x 10” (1200mm x 914mm x 254mm) oven compartment interior
Aluminized steel baking compartment liner
Aluminized steel combustion chamber
QHT Rokite deck supported by an angle iron frame
Two free-floating, easily removable duplex-tube burners
Removable fixed orifices on main and pilot burners
Main gas valve, temperature control valve and safety pilot valve fully within section body and are accessible through a covered and ventilated compartment in front
Air mixers with adjustable air shutters and locking device
Snap throttle thermostat with temperature control range of 300°F (149°C) to 650°F (343°C)
