Details
Overview
- Brews into 1gal to 1.5gal (3.8 to 5.7L) ThermoFresh® servers with base for easy transport of coffee to other locations
- BrewWISE® intelligence with pre-infusion and pulse brew for maximum flavor extraction
- Compatible with BUNNlink®
- Digital display in English/Spanish for easier programming and control. Advertising messages and machine status also displayed. Display capable of showing English or Metric measurements.
- Easy pulse display allows for simplified programming of pulse routine
- Energy-saver mode reduces tank temperature during idle periods
- Large 5.6gal (21.2L) tank provides back-to-back brewing capacity at 120/208-240V applications
- Three brew buttons allow for 3 separate brewing profiles. Two programmable batch switches allow full and half batch brewing
- 26.0" x 20.6" x 10.2"
- Stainless finish
- Stainless steel funnel
Electrical Configuration
- Volts-Factory Wired: 120V
- Phase-Factory Wired: 1
- Watts-Factory Wired: 1700W
- Hertz-Factory Wired: 60Hz
- Amps-Factory Wired: 14amps
Electrical Configuration Option 1
- Volts at Opt 1 Wiring: 120V
- Watts at Opt 1 Wiring : 1700W
- Amps at Opt 1 Wiring : 14amps
-
Coffee Capacity (Servings/Hour): 78.4
Electrical Configuration Option 2
- Volts at Opt 2 Wiring : 120V/208V
- Watts at Opt 2 Wiring : 2900W
- Amps at Opt 2 Wiring : 13.8amps
-
Coffee Capacity (Servings/Hour):
136
Electrical Configuration Option 3
- Volts at Opt 3 Wiring : 120V/240V
- Watts at Opt 3 Wiring : 4050W
- Amps at Opt 3 Wiring : 16.8amps
- Coffee Capacity (Servings/Hour): 180.8
| Water Access: |
Plumbed
|
|
Volts-Factory Wired:
|
120V |
| Coffee Capacity Range: | Medium |
| Number Of Wires (+GND): | 2 |
| Cord Attached: | Yes |
| plug type: | NEMA 5-15P |
| 2D Format CAD Available: | Yes |
| Minimum Input Pressure: | 20 PSI |
| Maximum Input Pressure: | 90 PSI |
| Inlet Water Fitting: | 3/8" Male Flare Fitting |
| Faucet Location: | Upper |
US SKU: 36600.0000
Server and airpot sold separately
