Details
Overview
STANDARD PRODUCT FEATURES
• High Quality Stainless Steel Construction
• Anodized Aluminum Interior
• LED Display Control for Accuracy and Easy Monitoring
• Stay Open Door Feature at 105°
• Capillary Tube Metering Device
• 12" Deep, 3/4" Thick, Full Length Removable Cutting Board
• NSF Approved White Polyethylene Board
• Maintains Cabinet Temperature of 32°F to 41°F
• NSF Rated for Use with 6" Deep Pans
• Top Cut-Out Accommodates 1/6 Size Pans (4" deep plastic
pans provided)
• Two (2) Adjustable, Heavy Duty Epoxy Coated Shelves
Per Section
• Field Reversible Door(s)
• Set of Four (4) 4" High Casters with Locks Standard
on Front Casters
• Gasket-Protecting Retainer
• Self-Contained Rear-Mounted Refrigeration System
• High-Density, Non-CFC Foamed in Place Polyurethane
Insulation
• 3 Year Parts & Labor Warranty, Additional 2 Years on
Compressor Parts
CONSTRUCTION, HARDWARE, INSULATION
Cabinet exterior front, sides, and door(s) are constructed of stainless
steel. Cabinet interior is constructed of anodized aluminum. 1/6 size
plastic pans and a set of four (4) 4” high casters are included. Doors
are equipped with a gasket protecting retainer. Both the cabinet and
door(s) are insulated with an average of 2-3/8” thick high density, non-
CFC, foamed in place polyurethane insulation.
REFRIGERATION SYSTEM
A rear mounted, self-contained, balanced refrigeration system using
environmentally friendly, non-flammable R-450A refrigerant is provided.
It features an easy to clean rear facing condenser, capillary tube metering
device, and an air-cooled hermetic compressor. A 9’ cord and plug is
provided. Standard operating temperature is 32°F to 41°F.
Energy efficient refrigeration system maintains safe product temperatures.
Condenser is located in back of unit for easy maintenance and zero
clearance.
CONTROLLER
The easy to use electronic digital control is supplied standard. It includes
a 3-Digit LED display, and a Fahrenheit or Celsius temperature scale
display capability.
INTERIOR
Standard interior arrangements include two (2) epoxy coated wire shelves
per section, mounted on pilasters. Recommended load limit per shelf
should not exceed 150 lbs.
