Details
Overview
OPEN BURNERS
- Anti-clogging burner 21% more efficient than other manufacturers’ heavy duty burners.
- 35,000 BTU/hr. (10 KW) output with a 7,000 BTU/hr. low simmer feature.
- One-piece venturi base has no gaskets. Venturi slopes down to the burner creating more efficient heating.
- Cast-iron burners remove and separate for cleaning.
- All stainless steel pilot tubing and solid brass top burner valves for a long service life.
- Wavy grates create more heat transfer. Heat convects in waves for continual heat-to-pan contact.
- IHR-6 series grates measure 12" x 14" (305 x 356 mm). IHR-4 series measure 18" x 14" (457 x 356 mm)
- Cast-iron design features flame shaping center tube for more efficient heat transfer.
- Anti-clogging shield designed into the grate protects the pilot from grease and debris.
- 40,000 BTU/hr (12 KW) oven with 100% safety pilot and manual shut-off valve.
- Unique burner baffle distributes heat flow to provide even temperatures throughout the oven cavity.
- Exclusive heat deflector reflects heat into the oven, not the floor.
- Chef Depth interior is 26-1/2" w x 26" d x 14" h (673 x 660 x 356 mm) and accommodates 18" x 26" (457 x 660) sheet pans left-to-right and front-to-back.
- Porcelainized sides, rear, deck and inner door liner for easy cleaning.
- Superior heavy-duty door hinge.
- Side oven controls are protected in the cool zone.
- One chrome oven rack is included.
