Details
Overview
- Specifications: Port Size: 1/2" (F) NPT Max. air flow at 100 PSI: 127 SCFM* Max. Pressure Range: Polycarbonate Bowl 150 PSI Zinc with Sight Glass: 250 PSI Reduced Pressure Range: 5 to 250 PSI Temperature Range: Polycarbonate Bowl: 40°F to 120°F (4.4°C to 48.9°C) Zinc Bowl with sight glass: 40°F to 150°F (4.4°C to 65.6°C) Filtration: Standard: 40 Microns. Option: 5 Microns Body Material: Zinc Bowl Material: Polycarbonate with Guard or Zinc Bowl with Sight Glass Bowl Capacity: 8 oz. Drain: Manual Drain (For Internal Auto Drain, see Accessories) Regulator Construction: Aluminum Spring Cage. T-Handle. Diaphragm Operated. Relieving Type Weight: Polycarbonate Bowl: 7.7 lbs. Zinc Bowl: 8.9 lbs. Pressure Gauge Port Size: 1/4" (F) NPT Recommended Oil: TG366
