Details
Overview
FEATURES:
DESIGN
True’s commitment to using the highest quality materials and oversized refrigeration systems provides the user with colder product temperatures, lower utility costs, exceptional food safety, and the best value in today’s foodservice marketplace
REFRIGERATION SYSTEM
-
Factory engineered, self-contained, capillary tube system using environmentally friendly R290 hydrocarbon refrigerant that has zero (0)
ozone depletion potential (ODP), & three (3) global warming potential (GWP). - High capacity, factory balanced refrigeration system that maintains cabinet temperatures of 33°F to 38°F (.5°C to 3.3°C) for the best in food preservation.
- State of the art, electronically commutated evaporator and condenser fan motors. ECM motors operate at higher peak efficiencies and move a more consistent volume of air which produces less heat, reduces energy consumption, and provides greater motor reliability.
- Bottom mounted condensing unit positioned for easy maintenance. “No stoop” lower shelf maximizes visibility by raising merchandised products to a higher level.
CABINET CONSTRUCTION
- Exterior - non-peel or chip black powder-coated cold-rolled steel; durable and permanent.
- Interior - attractive, NSF approved, white aluminum liner with stainless steel floor.
- Insulation - entire cabinet structure is foamed-in-place using a high density, polyurethane insulation that has zero ozone depletion potential (ODP) and zero global warming potential (GWP).
- Welded, heavy-duty steel frame rail, black powder-coated for corrosion protection.
- Frame rail fitted with leg levelers.
- Illuminated exterior sign panel. Variety of sign options available.
DOORS
- “Low-E”, double pane thermal insulated glass door assemblies with mitered plastic channel frames. The latest in energy-efficient technology.
- Each door is fitted with a 12” (305 mm) long handle.
- Self-closing doors. Counter-balanced weight system for smooth, even, positive closing.
SHELVING
- Eight (8) adjustable, heavy-duty PVC coated wire shelves 20 7/8” L x 20 9/16” D (531 mm x 523 mm). Four (4) chrome plated shelf clips are included per shelf.
- Shelf support pilasters are made of the same material as cabinet interior; shelves are adjustable on 1/2” (13 mm) increments.
LIGHTING
- LED interior lighting provides more even lighting throughout the cabinet. Safety shielded.
MODEL FEATURES
- The evaporator is epoxy coated to eliminate the potential for corrosion.
- Convenient clean-out drain built-in cabinet floor
- Listed under NSF/ANSI Standard 7 for the storage and/or display of packaged or bottled product
ELECTRICAL
- Unit completely pre-wired at factory and ready for final connection to a 115/60/1 phase, 15 amp dedicated outlet. Cord and plug set included.
SPECIFICATIONS:
- Doors: 2
- Shelves: 8
- Width: 47 1/8"
- Depth: 29 5/8"
- Height: 78 5/8"
- HP: 1/2
- Voltage: 115/60/1
- Amps: 6.5
