Details
Overview
FEATURES:
DESIGN
True’s commitment to using the highest quality materials and oversized refrigeration systems provides the user with colder product temperatures, lower utility costs, exceptional food safety, and the best value in today’s foodservice marketplace
REFRIGERATION SYSTEM
- Factory engineered, self-contained, capillary tube system using environmentally friendly R290 hydro carbon refrigerant that has zero (0) ozone depletion potential (ODP), & three (3) global warming potential (GWP).
-
High capacity, factory balanced refrigeration system that maintains cabinet temperatures of 33°F to 38°F (.5°C to 3.3°C) for the best in food
preservation. - State of the art, electronically commutated evaporator and condenser fan motors. ECM motors operate at higher peak efficiencies and move a more consistent volume of air which produces less heat, reduces energy consumption, and provides greater motor reliability.
- Condensing unit access in the back of the cabinet slides out for easy maintenance.
CABINET CONSTRUCTION
- Exterior - stainless steel front, top, and ends. Matching aluminum finished back.
- Interior - attractive, NSF approved, clear coated aluminum liner. Stainless steel floor with coved corners.
- Insulation - entire cabinet structure and solid doors are foamed-in-place using a high density, polyurethane insulation that has zero ozone depletion potential (ODP) and zero global warming potential (GWP).
- 5" (127 mm) diameter stem castors - locks provided on front set. 36" (915 mm) work surface height.
DOORS
- Stainless steel exterior with a clear aluminum liner to match cabinet interior.
- Each door is fitted with a 12" (305 mm) long recessed handle that is foamed-in-place with a sheet metal interlock to ensure permanent attachment.
- Positive seal self-closing doors with 90° stay open feature. Doors swing within cabinet dimensions.
- Magnetic door gaskets of one-piece construction, removable without tools for ease of cleaning.
SHELVING
- Four (4) adjustable, heavy-duty PVC coated wire shelves 21 9/16"L x 16" D (548 mm x 407 mm). Four (4) chrome plated shelf clips are included per shelf.
- Shelf support pilasters are made of the same material as cabinet interior; shelves are adjustable on 1/2" (13 mm) increments.
MODEL FEATURES
- The evaporator is epoxy coated to eliminate the potential for corrosion.
- 8 7/8" (226 mm) deep,1/2" (13 mm) thick, full-length removable cutting board. Sanitary, high-density, NSF approved white polyethylene provides a tough preparation surface
- Stainless steel, patented, foam insulated lid and hood keep pan temperatures colder, lock in freshness and minimize condensation. Removable for easy cleaning
-
Comes standard with 18 (1/6size) 67/8"L x 61/4” W x 4" D (175 mm x 159 mm x 102 mm) clear polycarbonate, NSF approved, food pans in
countertop prep area. Also accommodates 6" (153 mm) deep food pans (supplied by others). - Countertop pan opening designed to fit varying size pan configurations with available pan divider bars. Varying size pans supplied by others.
- NSF-7 compliant for open food product.
ELECTRICAL
- Unit completely pre-wired at factory and ready for final connection to a 115/60/1 phase, 15 amp dedicated outlet. Cord and plug set included.
SPECIFICATIONS:
- Doors: 2
- Shelves: 4
- Pan (Top): 18
- Width: 48 3/8"
- Depth: 34 1/8"
- Height: 40 3/8"
- HP: 1/3
- Voltage: 115/60/1
- Amps: 5.8
