Details
Overview
FEATURES:
REFRIGERATION SYSTEM
Factory engineered, self-contained, capillary tube system using environmentally friendly (CFC free) 134A refrigerant.
High capacity, factory balanced refrigeration system that maintains cabinet temperatures of 33°F to 38°F (.5°C to 3.3°C) for the best in food preservation.
State of the art, electronically commutated evaporator and condenser fan motors. ECM motors operate at higher peak efficiencies and move a more consistent volume of air which produces less heat, reduces energy consumption, and provides greater motor reliability
Top-mounted refrigeration system with evaporator positioned out of food zone.
Electronic control
CABINET CONSTRUCTION
Insulation - entire cabinet structure is foamed-in-place using Ecomate. A high density, polyurethane insulation that has zero ozone depletion potential (ODP) and zero global warming potential (GWP).
5" (127 mm) diameter plate castors - locks provided on front set.
DOORS
“Low-E”, double pane thermal insulated glass.
Lifetime guaranteed bolt style door lock standard.
Lifetime guaranteed heavy duty all metalworking door handle
Positive seal self-closing door with 120° stay open feature. Lifetime guaranteed external cam lift door hinges, four (4) per door section
Magnetic door gaskets of one-piece construction, removable without tools for ease of cleaning.
SHELVING
STR Series Shelving - (3) heavy-duty, chrome-plated wire shelves per section. Shelves are 22 13/16” L x 25 5/16” D (580 mm x 643 mm). Four (4) chrome plated shelf clips are included per shelf.
LIGHTING
Vertical LED interior lighting mounted on the interior of the cabinet. Lighting runs the entire length of the door opening. Safety shielded.
MODEL FEATURES
Exterior digital temperature display, available with either °F or °C
Evaporator epoxy coated to eliminate the potential of corrosion
Curb mounting ready
NSF-7 compliant for open food products.
ELECTRICAL
Unit completely pre-wired at factory and ready for final connection to a 115/60/1 phase, 15 amp dedicated outlet. Cord and plug set included.
DIMENSIONS:
- Doors: 1
- Shelves: 3
- Length: 27.5"
- Depth: 33.75"
- Height: 77.75"
- HP: 0.33
- Voltage: 115/60/1
- Amps: 4.8
