Ellipsoidal bottom kettle liner formed and fully welded standard type 316 and type 304 stainless steel exterior
Heavy bar rim (1⁄4 x 5⁄8 inch 20 gallons) (3⁄8 x 1 inch 40 gallons and greater)
Embossed gallon/liter markings
Faucet bracket
50 psi (3.4 kg/cm2) steam jacket rating
Spring assist hinged stainless steel cover with condensate ring and drop down lift handle with heavy duty pivot assembly that includes a yolk style mount with tie bar
Two inch compression tangent draw-off valve with perforated strainer
Tubular stainless steel legs with flanged feet
Stainless steel enclosure for “water resistant” controls
Controls include a power switch, power “on” light, solid state temperature control, vacuum/pressure gauge, pressure relief valve,low water light and low water shut-off
Elevation from sea level to 8,999 feet standard, for higher elevation consult factory
