PASTA PRODUCTION STATION
TUBE FIRED BURNERS
STAINLESS STEEL VESSELS
EXTERIOR FEATURES
- Exclusive water wash system removes the starch evenly across the entire surface of the water and reduces foaming.
- Water replacement can be adjusted from 1 gallon (3.8 L) per hour to 3 gallons (11 L) per minute depending on the specific need.
- Vessel is 16 gauge 317 alloy stainless steel. This “higher-than-marine-grade” withstands stronger concentrations of salt in the water for faster pasta preparation without boiling the water. Boiling can compromise the flavor.
- Drain is 1¼" (32) diameter for quick, easy draining
TUBE FIRED BURNERS
- Even heat is delivered through a large oval heat exchanger tube.
- A unique baffle design efficiently transfers heat into the water throughout the entire vessel.
- The tube design and water wash system create a natural convection action to recirculate fresh hot water into the vessel.
- Millivolt temperature control circuit.
- 100% safety shut-off.
STAINLESS STEEL VESSELS
- Vessel is 16 gauge 317 alloy stainless steel. This “higher-thanmarine- grade” withstands stronger concentrations of salt in the water for faster pasta preparation.
- Vessel tubes and sides are robotically welded stainless steel to virtually eliminate leaks.
- Recessed bottom facilitates draining, slants toward the drain.
- 1-1/4" (32 mm) full port drain valve empties vessel quickly and safely.
EXTERIOR FEATURES
- Stainless steel front, door, sides and vessel.
- Welded and polished stainless steel seams.
- Full bottom chassis provide structural support.
- Plate mounted 6" (152 mm) heavy duty casters.
- One year parts and labor warranty. Limited warranty on vessel, stainless steel vessel is five years pro-rated.
