Details
- Dispenses hot water in three portion sizes
- Front of machine volume programming
- Precise temperature (60°F-210ºF) (15.5ºC- 98.9ºC) ensures consistent, high quality results; adjustable in 1º increments
- Three programmable volume settings and one push and hold continuous dispense button
- All stainless design
- Locate hot water at preparation site to increase speed, safety and efficiency of kitchen staff
- Dual voltage adaptable (Can operate at 120V/15 amp or 120/208-240V/20 amp)
Electrical Configuration
- Volts-Factory Wired: 120V/208V-240V
- Phase-Factory Wired: 1
- Watts-Factory Wired: 4050W
- Hertz-Factory Wired: 60Hz
- Amps-Factory Wired: 16.9amps
Electrical Configuration Option 1
- Volts at Opt 1 Wiring: 120V
- Watts at Opt 1 Wiring : 1850W
- Amps at Opt 1 Wiring : 15.4amps
-
Capacity at 35°F Input (Servings/Hour): 59.2
- Capacity at 140°F Input (Servings/Hour : 192
Electrical Configuration Option 2
- Volts at Opt 2 Wiring : 120V/208V
- Watts at Opt 2 Wiring : 3054W
- Amps at Opt 2 Wiring : 14.7amps
-
Capacity at 35°F Input (Servings/Hour): 116.8
- Capacity at 140°F Input (Servings/Hour): 320
Electrical Configuration Option 3
- Volts at Opt 3 Wiring : 120V/240V
- Watts at Opt 3 Wiring : 4050W
- Amps at Opt 3 Wiring : 16.9amps
-
Capacity at 35°F Input (Servings/Hour): 155.2
- Capacity at 140°F Input (Servings/Hour): 427.2
| Water Access: | Plumbed |
|
Volts-Factory Wired: | 120V |
| Water Capacity Range: | Medium |
| Number Of Wires (+GND): | 3 |
| Cord Attached: | No |
| 2D Format CAD Available: | Yes |
| Minimum Input Pressure: | 20 PSI |
| Maximum Input Pressure: | 90 PSI |
| Inlet Water Fitting: | 1/4" Male Flare Fitting |
| Temp/Time Setting: | 200° F |
| Faucet Location: | Upper |
US SKU: 39100.0000
Server and airpot sold separately
