Details
Vue d’ensemble
- Countertop or under the counter, steri-center installation.
- G4 web portal includes data storage, service logs and remote access capabilities
- Validated cycles to ensure repeatable washing performance
- Improved serviceability, reliability and minimal maintenance requirements
- Vivid color touch screen
- Robust stainless steel exterior
- USB port for data storage
- Active hot air drying
SciCan Hydrim Product Prochure - Click Here
|
CONNECT |
PROTECT |
COLLECT |
|
|
|
 |
| The HYDRIM G4 is capable of communicating directly with service personnel or anyone you choose. Should the HYDRIM G4 ever need attention, diagnostic information can be sent via email to pre-selected dealer service reps, significantly reducing down time. |
The HYDRIM G4 supports verifiable processes that are PIN protected with user-defined IDs so that staff members can be required to authorize a cycle. This encourages extra attention to process and creates a safer environment for both staff and patient. |
With each cycle, information must be stored to protect your office and your patients. The integrated data logger store all cycle information for the lifetime of the unit. A USB port allows for the manual retrieval of cycle history. The 10/100 Base-T Ethernet connection puts your PC in direct contact with your HYDRIM G4 and the RS232 serial printer port allows you to connect with an external |
|
HYDRIM MEETS THE INTERNET |
|
|
|
A high-resolution, 65K color touch screen offers a vivid display of messages, current cycle information and customizable colors all with extraordinary clarity. Fully adjustable contrast levels let you optimize the screen to the lighting in your steri-center, and it's 2.5-inch by 3-inch dimensions allow easy viewing of cycle information. |
| Large chamber volume - Six full size IMS cassette capacity, 120 instruments in 35 minutes start-to-dry |
HIP ULTRA cleaning solution is stored in the unit, so no extra storage space requirements |
 |
 |
| Large variety of furniture options available | IMS cassettes or open basket options |
 |
 |
|
HYDRIM C61w SPECIFICATIONS |
|
| Dimensions: (w x h x d) | 598 x 520 x 526mm (23.5" x 20.5" x 20.7") |
| Depth with door open: | "82.9 cm / 32.6 |
| Weight: | 44 kg / 97 lbs |
| Cycle Times* | |
| Rinse and Hold | 5 mins |
| Regular Wash + Dry | 26 mins. + 10 mins. |
| Heavy Duty Wash + Dry | 30 mins. + 10 mins. |
| Water Consumption Per Cycle: | |
| Rinse and Hold | 7.6 litres / 2 gallons |
| Regular Wash | 11.5 litres / 3 gallons |
| Heavy Duty Wash | 11.5 litres / 3 gallons |
| Electrical Connection | |
| Electrical Rating: | 208-240V, 12A, 60 Hz |
| Running noise: | < 65 dB |
| Water and Drain Connections | |
| Hot and Cold Water Tap Connection | 3/4" Garden hose, male |
| Recommended Hot Water Temperature | 60°C / 140°F |
| Cold Water Temperature | < 30°C / 86°F |
| Inlet Water Pressure | 1 - 10 bar / 14.5 - 145 psi |
| Drain | 2 cm / 3/4" |
