Details
Vue d’ensemble
- Under counter steri-center installation, but can also be a freestanding unit
- G4 web portal interface includes data storage, service logs and remote access capabilities
- Validated cycles to ensure repeatable washing performance
- Ten 8" x 11" IMS cassette capacity
- USB port for data storage
- Robust stainless steel exterior includes pump for liquid detergent
- Web based documentation software included, no installation required
- Active hot air drying
- Manufactured in Canada
SciCan Hydrim Product Prochure - Click Here
|
CONNECT |
PROTECT |
 |
 |
|
The HYDRIM G4 is capable of communicating directly with service personnel or anyone you choose. Should the HYDRIM G4 ever need attention, diagnostic information can be sent via email to pre-selected dealer service reps, significantly reducing down time. |
The HYDRIM G4 supports verifiable processes that are PIN protected with user-defined IDs so that staff members can be required to authorize a cycle. This encourages extra attention to process and creates a safer environment for both staff and patient. |
|
COLLECT |
HYDRIM MEETS THE INTERNET |
 |
 |
|
With each cycle, information must be stored to protect your office and your patients. The integrated data logger store all cycle information for the lifetime of the unit. A USB port allows for the manual retrieval of cycle history. The 10/100 Base-T Ethernet connection puts your PC in direct contact with your HYDRIM G4 and the RS232 serial printer port allows you to connect with an external printer. |
A high-resolution, 65K color touch screen offers a vivid display of messages, current cycle information and customizable colors all with extraordinary clarity. Fully adjustable contrast levels let you optimize the screen to the lighting in your steri-center, and it's 2.5-inch by 3-inch dimensions allow easy viewing of cycle information. |
|
HYDRIM L110w can process 2,500 instruments in a 10-hour day |
Outer surfaces of dental handpieces can be cleaned with the handpiece holder |
 |
 |
|
Large variety of furniture options available |
HIP Cleaning solution is stored in the unit, so no extra storage space requirements |
 |
 |
|
HYDRIM L110w G4 SPECIFICATIONS |
|
| Dimensions: (w x h x d) | 600 x 850 x 600 mm (23.8" x 33.5" x 23.8") |
| Depth with door open: | 1200 mm / 47" |
| Weight: | 80 kg / 176 lbs. |
| Cycle Times:* | |
| Rinse and Hold | 17 mins |
| Regular Wash + Dry | 25 mins. + 10 mins. |
| Heavy Duty Wash + Dry | 34 mins. + 10 mins. |
| Water Consumption Per Cycle: | |
| Rinse and Hold | 16 litres / 4.28 gallons |
| Regular Wash | 16 litres / 4.28 gallons |
| Heavy Duty Wash | 32 litres / 8.45 gallons |
| Electrical Connection | |
| Electrical Rating: | 208-240V, 12A, 60 Hz |
| Running noise: | < 78 dB |
| Water and Drain Connections | |
| Hot and Cold Water Tap Connection | 3/4" Garden hose, male |
| Recommended Hot Water Temperature | 60°C / 140°F |
| Cold Water Temperature | < 30°C / 86°F |
| Inlet Water Pressure | 1 - 10 bar / 14.5 - 145 psi |
| Drain | 2 cm / 3/4" |
